SMS GSM Modem

[vikty]

Hi,

How can I use the modem GSM to send SMS?
must I install anything? must I follow any procedure?

I have a Siemens TC35... is there any problem???

[Alexei]

Siemens TC35 works absolutely fine. I used it some time ago, nice hardware.

[vikty]

thank you

This resolve any problem

[vikty]

How to use

Hi,

Can you explain how to use the SMS media types?
I have done
1) config the Media type wiht /dev/ttyS0
2) Add new media type in user account
3) in "Send to" box I have written my tel number 348xxxxxxx
4) I have configured the action to send me the alarm normaly....
After this the SMS is not arrived...

I think that the problem is the GSM modem, but I don't know how to test if the GSM Modem is corectly recognized
How can I do?

[vikty]

How to testing

Hi,
This is a mini "How to" for GSM modem:

1) Use minicom with /dev/ttyS0 and 9600bps
2) Test some AT comand (AT, AT+CPIN?)
After
3) Read in zabbix interface Monitoring > Action, why it doesn't work.
4) Set permission "chmod 666 /dev/ttyS0"
5)Try an action...
6)GOOD LOOK

[vikty]

/dev/ttyS0 Permition deny

mmhh.. but...
Why must I do this "chmod 666 /dev/ttyS0"?
I don't think that is a normal operation...but Zabbix user can't write in /dev/ttyS0
Can someone explain me this..??

[Alexei]

Under Ubuntu, you may simply add user "zabbix" to group "dialout". No change of /dev/ttyS0 permissions is required.

[vikty]

I use Fedora Core 6...
anyway I can retry.

[vikty]

In fedora there isn't dialout group, but there is uucp group
I have tryed to add zabbix user in uucp group, but when I try to send a SMS

Error open(/dev/ttyS0) [Permission denied]

fine.. just I will find anything I will post it here...

[bee]

Expected [OK] received []

After few weeks trial and doing every possible trick, ZABBIX still won't send sms out. It always return with error:
Expected [OK] received []

My GSM modem is iTegno W3800 SE with serial port. My ZABBIX hosted on FreeBSD 7.0-STABLE. ZABBIX it self have version:

ZABBIX Server (daemon) v1.4.5 (25 March 2008)
Compilation time:  May  9 2008 15:19:12

Send manual sms using AT command via minicom, no issue at all, works very charm.

i did many times recompile of sms.c, change any possible trick from step 0 till step 9 and did any advice posted in this thread but none work. ALways return with Expected [OK] received []

Is there any still possible trick for me to make it work?! What is exactly Expected [OK] received [] means?

/*  0  */       {ZBX_AT_ESC     , NULL          , 0     },      /* Send <ESC> */
/*  1  */       {"AT+CMEE=2\r"  , "OK"          , 5     },      /* verbose error
/*  1  */       {"ATE0\r"       , "OK"          , 5     },      /* Turn off echo
/*  2  */       {"AT\r"         , "OK"          , 5     },      /* Init modem */
/*  3  */       {"AT+CMGF=1\r"  , "OK"          , 5     },      /* Switch to tex
/*  4  */       {"AT+CMGS=\""   , NULL          , 0     },      /* Set phone num
/*  5  */       {number         , NULL          , 0     },      /* Write phone n
/*  6  */       {"\"\r"         , "> "          , 5     },      /* Set phone num
/*  7  */       {message        , NULL          , 0     },      /* Write message
/*  8  */       {ZBX_AT_CTRL_Z  , "+CMGS: "     , 40    },      /* Send message
/*  9  */       {NULL           , "OK"          , 1     },      /* ^Z */
/* EOS */       {NULL           , NULL          , 0     }

[bee]

Error during wait for GSM modem (bit clue)

Hi,

Today i'm reproduce the error again, and capture this from log:

[COLOR="Red"]68603:20080512:102426 Error during wait for GSM modem.[/COLOR]
 68603:20080512:102426 Read from GSM modem []
]68603:20080512:102426 Write to GSM modem [
 68603:20080512:102426 Read from GSM modem []

is it because my GSM modem need a longer time to respond zabbix's initialization? Can i do increase the value of "timed_out" setting from this initialization?

Any advice?

Thanks,
BEE

[bee]

Hi All
Now sms feature works for me. Nothing wrong with sms.c code. In my case, it's only serial ports configuration issue. You can find detail in my below post:

http://www.zabbix.com/forum/showthread.php?t=8666&highlight=SMS&page=2

Thanks,
BEE

[wachsiman]

Hi,

i had the same problem.

Expected [OK] received []

The serial Interface ttyS0 was on 9600 bps.
If the speed was 9600 bps i get the failure Expected [OK] received [].

I configured the serial interface on 115200 bps.
Thats solve the problem.
Now i can send sms over the gsm modem.

Sorry for the bad english ...

[ldil]

Hi all,

Best thing that i have used is gnokki with this script.
Gnokki can work with any GSM device.
Within zabbix you use this script and place this script in /home/zabbix/bin
Media type is script within the user SMS +316460xxxxx 1-7,08:00-22:00; NIWAHD Enabled

#!/bin/sh

HOME=/etc
PATH=/bin:/sbin:/usr/bin:/usr/sbin
LOGFILE="/var/log/zabbix-sms.log"

echo "Recipient='$1' Message='$3'" >> ${LOGFILE}

MOBILE_NUMBER=`echo "$1" | sed s#\s##`

# Log it
echo "echo $3 | /usr/bin/gnokii --sendsms ${MOBILE_NUMBER}" >>${LOGFILE}

# Send it
echo "$3" | /usr/bin/gnokii --sendsms "${MOBILE_NUMBER}" 1>>${LOGFILE} 2>&1

# EOF

[Mike78]

In fedora there isn't dialout group, but there is uucp group
I have tryed to add zabbix user in uucp group, but when I try to send a SMS

fine.. just I will find anything I will post it here...

zabbix_server needs to be restarted after zabbix user added to the uucp group.
