Zabbix pre 5 MySQL

[[email protected]]

Hi, i can't monitoring zabbix mysql database

error:

Zabbix server MySQL: Failed to get items (no data for 30m)

Macros are configured correctly

[gofree]

do you monitor via agent ? version of the zabbix and agent ? what template ? does the user exist in the db - what rights does it have ? whats the error in the logs? ...you need to provide bit more info on the topic

[[email protected]]

OK sorry for minimal information
here report:




Zabbix Agent
zabbix_agentd (daemon) (Zabbix) 5.0.0rc1
Revision ffde654900 5 May 2020, compilation time: May 5 2020 07:00:00

Template:Template DB MySQL by Zabbix agent on zabbix server 5.0.0rc1

grant MySQL user:

MariaDB [(none)]> SHOW GRANTS FOR 'zbx_monitor';
+------------------------------------------------------------------------------- ------------------------------------------------------------------------------+
| Grants for zbx_monitor@% |
+------------------------------------------------------------------------------- ------------------------------------------------------------------------------+
| GRANT PROCESS, SHOW DATABASES, REPLICATION CLIENT, SHOW VIEW ON *.* TO 'zbx_mo nitor'@'%' IDENTIFIED BY PASSWORD '*016DEE8FAE643B3B63C38EBD87D707EC037555AF' |
+------------------------------------------------------------------------------- ------------------------------------------------------------------------------+
1 row in set (0.000 sec)



In /etc/zabbix/ i've added .my.cnf file:


#template_db_mysql.conf created by Zabbix for "Template DB MySQL" and Zabbix 4.2
#For OS Linux: You need create .my.cnf in zabbix-agent home directory (/var/lib/zabbix by default)
#For OS Windows: You need add PATH to mysql and mysqladmin and create my.cnf in %WINDIR%\my.cnf,C:\my.cnf,BASEDIR\my.cnf https://dev.mysql.com/doc/refman/5.7...ion-files.html
#The file must have three strings:
#[client]
user='zbx_monitor'
password='password'
#
UserParameter=mysql.ping[*], mysqladmin -h"$1" -P"$2" ping
UserParameter=mysql.get_status_variables[*], mysql -h"$1" -P"$2" -sNX -e "show global status"
UserParameter=mysql.version[*], mysqladmin -s -h"$1" -P"$2" version
UserParameter=mysql.db.discovery[*], mysql -h"$1" -P"$2" -sN -e "show databases"
UserParameter=mysql.dbsize[*], mysql -h"$1" -P"$2" -sN -e "SELECT COALESCE(SUM(DATA_LENGTH + INDEX_LENGTH),0) FROM INFORMATION_SCHEMA.TABLES WHERE TABLE_SCHEMA='$3'"
UserParameter=mysql.replication.discovery[*], mysql -h"$1" -P"$2" -sNX -e "show slave status"
UserParameter=mysql.slave_status[*], mysql -h"$1" -P"$2" -sNX -e "show slave status"


ERROR IN LOGS agent and Server nothing is attributable to this case

[gofree]

just a quick guess - maybe you cnf file is not in the right directory - /etc/zabbix maybe should be /etc/zabbix/zabbix_agent.d/

try to run some of the user parameters it might give you some output

https://www.zabbix.com/integrations/mysql

[[email protected]]

Ok create a folder zabbix under /var/lib create a .my.cnf file in that folder

[client]
user=zbx_monitor
password=<password>

Then download from git the template mysql by agent and copy to /etc/zabbix/zabbix_agentd.d$
cat template

#template_db_mysql.conf created by Zabbix for "Template DB MySQL" and Zabbix 4.2
#For OS Linux: You need create .my.cnf in zabbix-agent home directory (/var/lib/zabbix by default)
#For OS Windows: You need add PATH to mysql and mysqladmin and create my.cnf in %WINDIR%\my.cnf,C:\my.cnf,BASEDIR\my.cnf https://dev.mysql.com/doc/refman/5.7/en/option-files.html
#The file must have three strings:
#[client]
#user='zbx_monitor'
#password='<password>'
#
UserParameter=mysql.ping[*], mysqladmin -h"$1" -P"$2" ping
UserParameter=mysql.get_status_variables[*], mysql -h"$1" -P"$2" -sNX -e "show global status"
UserParameter=mysql.version[*], mysqladmin -s -h"$1" -P"$2" version
UserParameter=mysql.db.discovery[*], mysql -h"$1" -P"$2" -sN -e "show databases"
UserParameter=mysql.dbsize[*], mysql -h"$1" -P"$2" -sN -e "SELECT COALESCE(SUM(DATA_LENGTH + INDEX_LENGTH),0) FROM INFORMATION_SCHEMA.TABLES WHERE TABLE_SCHEMA='$3'"
UserParameter=mysql.replication.discovery[*], mysql -h"$1" -P"$2" -sNX -e "show slave status"
UserParameter=mysql.slave_status[*], mysql -h"$1" -P"$2" -sNX -e "show slave status"

No Macro configured on my host.
All works fine

only 1 error in template in attach
