Network discovery do not create graphs upon assigning template [5.4.3]

Collapse
X

  • Time
  • Show
Clear All
new posts
  • AkvenJan
    Junior Member
    • Jun 2021
    • 19

    #1

    Network discovery do not create graphs upon assigning template [5.4.3]

    I have a fresh installation of Zabbix 5.4.3 with all the defaults. I use default ZYXEL XGS-4728F SNMP Template. I created a discovery rule to scan my network, find all the 4728 and add them to Zabbix with assigning this template.
    This part is working, I got my devices with all the items created

    Click image for larger version

Name:	zbx1.png
Views:	312
Size:	79.2 KB
ID:	429114

    BUT
    For some reason Zabbix do not create graphs from template to discovered devices. There is one device I added to monitoring by hand, and all the graphs from the template were properly created. All other discovered devices do not have them despite of graphs present in template.

    If I unassign template and assign it back by hand - devices start to create graphs.

    How can I get my graphs for discovered hosts? I can't reassign template by hand to hundred of devices
  • AkvenJan
    Junior Member
    • Jun 2021
    • 19

    #2
    It seems that LLD Discovery from the template isn't working after discovering host.
    Triggers from LLD also aren't creating.
    Even if I manually start LLD Discovery - it doesn't really discovery triggers and graphs despite of having no errors. However items are discovered. It's very strange.
    If I reapply the same template and start LLD Discovery - everything is ok, triggers and graphs are created.

    But for Discovered hosts only main template triggers are creating, not whose from LLD.
