Hi,
Recently, I have updated my Zabbix server version to 4.0.1 from version 3.4.
In the previous version (3.4), I had a dashboard with a "Trigger overview" widget. I have set the "Show" option to the value "Any" so that the widget displays a green square when the associated trigger is in the OK state (i.e. the expression of the trigger is false). This configuration worked fine on Zabbix 3.4.
However, after updating to Zabbix 4.0.1, the green squares are only shown when all of the triggers in the widget are OK. If any one of the triggers have a problem (not in the OK state), the widget suddenly shows only its row and column. When all of the triggers are back in the OK state, the widget returns to showing all of the green squares. I did not find a way to make Zabbix show all of the rows and columns always – each one with the color that represents its status. It is possible in Zabbix 4.0.1?
Example (The black markings are not part of the problem
):
When all of the triggers are OK, this is how the widget looks like this:
When one the triggers is not in the OK state, the widget looks like this:
Why is Zabbix not showing the rest of the rows and columns that should be green, as in the previous image?
Thanks in advance.
Recently, I have updated my Zabbix server version to 4.0.1 from version 3.4.
In the previous version (3.4), I had a dashboard with a "Trigger overview" widget. I have set the "Show" option to the value "Any" so that the widget displays a green square when the associated trigger is in the OK state (i.e. the expression of the trigger is false). This configuration worked fine on Zabbix 3.4.
However, after updating to Zabbix 4.0.1, the green squares are only shown when all of the triggers in the widget are OK. If any one of the triggers have a problem (not in the OK state), the widget suddenly shows only its row and column. When all of the triggers are back in the OK state, the widget returns to showing all of the green squares. I did not find a way to make Zabbix show all of the rows and columns always – each one with the color that represents its status. It is possible in Zabbix 4.0.1?
Example (The black markings are not part of the problem
):When all of the triggers are OK, this is how the widget looks like this:
When one the triggers is not in the OK state, the widget looks like this:
Why is Zabbix not showing the rest of the rows and columns that should be green, as in the previous image?
Thanks in advance.
