SNMP traps presentation at GUI

[manosnms]

Hello,

I have 2 issues.

1. Even though i put MIB files under /usr/local/share/snmp/mibs (https://www.zabbix.com/documentation...ypes/snmp/mibs) it seems that Zabbix cannot translate the traps



2. Is it possible to have another view of the traps? e.g.




Thank you

[tim.mooney]

1. Even though i put MIB files under /usr/local/share/snmp/mibs (https://www.zabbix.com/documentation...ypes/snmp/mibs) it seems that Zabbix cannot translate the traps

That's not Zabbix's fault, that's because snmptrapd isn't doing the translation.

You need to modify your OS's snmp configuration to load the MIBs you need.

You don't say what OS or version you're using, but if it's RHEL or a related distro, read the snmp.conf(5) man page and pay attention to the "MIB HANDLING" section.

For my site, where the Zabbix server is currently on RHEL 7.x, I created the file /etc/snmp/snmp.local.conf and put several "mibs + MIBNAME" statements in it. Remember to restart snmptrapd after making any changes to snmp.conf, snmp.local.conf, or snmptrapd.conf.

[manosnms]

Hi,

Is it possible to provide a simple example?

e.g a few MIBs I have

mibs + /usr/local/share/snmp/mibs/BGP4-MIB
mibs + /usr/local/share/snmp/mibs/BRIDGE-MIB
mibs + /usr/local/share/snmp/mibs/CISCO-BGP4-MIB
mibs + /usr/local/share/snmp/mibs/CISCO-EIGRP-MIB
mibs + /usr/local/share/snmp/mibs/CISCO-ENTITY-ASSET-MIB


I have Centos7

Thank you

[manosnms]

What I have

[root@zabbix zabbix]# net-snmp-config --snmpconfpath
/etc/snmp:/usr/share/snmp:/usr/lib64/snmp:/root/.snmp:/var/lib/net-snmp

I put all of my mibs under /usr/share/snmp/mibs

I created a file named snmp.local.conf and I added the below

mibs +ALL

so now when I restart snmptrapd

I get the below

[root@zabbix zabbix]# systemctl status snmptrapd -l
● snmptrapd.service - Simple Network Management Protocol (SNMP) Trap Daemon.
Loaded: loaded (/usr/lib/systemd/system/snmptrapd.service; enabled; vendor preset: disabled)
Active: active (running) since Fri 2020-07-03 12:50:55 EEST; 5min ago
Main PID: 6915 (snmptrapd)
Tasks: 1
CGroup: /system.slice/snmptrapd.service
└─6915 /usr/sbin/snmptrapd -On -Lsd -f

Jul 03 12:56:00 zabbix snmptrapd[6915]: Cannot adopt OID in MPLS-MIB: mplsLspName ::= { mplsLspEntry 1 }
Jul 03 12:56:00 zabbix snmptrapd[6915]: perl callback function 0x55fb6d8b28c0 returns 1
Jul 03 12:56:02 zabbix snmptrapd[6915]: perl callback function 0x55fb6d8b28c0 returns 1
Jul 03 12:56:02 zabbix snmptrapd[6915]: perl callback function 0x55fb6d8b28c0 returns 1
Jul 03 12:56:02 zabbix snmptrapd[6915]: perl callback function 0x55fb6d8b28c0 returns 1
Jul 03 12:56:03 zabbix snmptrapd[6915]: perl callback function 0x55fb6d8b28c0 returns 1
Jul 03 12:56:03 zabbix snmptrapd[6915]: perl callback function 0x55fb6d8b28c0 returns 1
Jul 03 12:56:03 zabbix snmptrapd[6915]: perl callback function 0x55fb6d8b28c0 returns 1
Jul 03 12:56:04 zabbix snmptrapd[6915]: perl callback function 0x55fb6d8b28c0 returns 1
Jul 03 12:56:09 zabbix snmptrapd[6915]: perl callback function 0x55fb6d8b28c0 returns 1

[root@zabbix zabbix]# systemctl status snmptrapd -l
● snmptrapd.service - Simple Network Management Protocol (SNMP) Trap Daemon.
Loaded: loaded (/usr/lib/systemd/system/snmptrapd.service; enabled; vendor preset: disabled)
Active: active (running) since Fri 2020-07-03 12:50:55 EEST; 5min ago
Main PID: 6915 (snmptrapd)
Tasks: 1
CGroup: /system.slice/snmptrapd.service
└─6915 /usr/sbin/snmptrapd -On -Lsd -f

Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityPathVectorLimit ::= { jnxMplsLdpEntityEntry 14 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityLabelRetentionMode ::= { jnxMplsLdpEntityEntry 13 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityLabelDistMethod ::= { jnxMplsLdpEntityEntry 12 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityInitSesThreshold ::= { jnxMplsLdpEntityEntry 11 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityHelloHoldTimer ::= { jnxMplsLdpEntityEntry 10 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityKeepAliveHoldTimer ::= { jnxMplsLdpEntityEntry 9 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityMaxPduLength ::= { jnxMplsLdpEntityEntry 8 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityUdpDscPort ::= { jnxMplsLdpEntityEntry 7 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityTcpDscPort ::= { jnxMplsLdpEntityEntry 6 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityOperStatus ::= { jnxMplsLdpEntityEntry 5 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityAdminStatus ::= { jnxMplsLdpEntityEntry 4 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityProtocolVersion ::= { jnxMplsLdpEntityEntry 3 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityIndex ::= { jnxMplsLdpEntityEntry 2 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityLdpId ::= { jnxMplsLdpEntityEntry 1 }
Jul 03 12:56:33 zabbix snmptrapd[6915]: Cannot adopt OID in JUNIPER-MPLS-LDP-MIB: jnxMplsLdpEntityStatsEntry ::= { jnxMplsLdpEntityStatsTable 1 }

[manosnms]

any help would be great. thanks

[tim.mooney]

I've not seen that particular error ( "Cannot adopt OID" ) before, but some web searching turns up a number of matches for it. Based on a very quick glance at a couple of them, it seems like it may be some kind of dependency issue. You'll want to do some research on that error and look at some of the search results, to see if you arrive at the same conclusion.

If it is a dependency error, it probably means that either you're missing some MIB files that other MIBs need or possibly they're getting loaded in the wrong order? Not sure, as again I haven't experienced this particular error.

[manosnms]

I don't get it.

the perl file is working. the SNMPTrapperFile is working fine.

an example is the below.

17:28:53 2020/07/13 ZBXTRAP 10.13.5.21
PDU INFO:
notificationtype TRAP
version 1
receivedfrom UDP: [10.10.0.10]:58660->[10.10.0.2]:162
errorstatus 0
messageid 0
community something
transactionid 967
errorindex 0
requestid 1703803143
VARBINDS:
.1.3.6.1.2.1.1.3.0 type=67 value=Timeticks: (687914106) 79 days, 14:52:21.06
.1.3.6.1.6.3.1.1.4.1.0 type=6 value=OID: .1.3.6.1.2.1.10.166.3.0.2
.1.3.6.1.2.1.10.166.3.2.2.1.34.48559.1.1051328316. 1051328286 type=2 value=INTEGER: 1
.1.3.6.1.2.1.10.166.3.2.2.1.35.48559.1.1051328316. 1051328286 type=2 value=INTEGER: 2
.1.3.6.1.6.3.1.1.4.3.0 type=6 value=OID: .1.3.6.1.4.1.2636.1.1.1.2.21

this is a CiscoIOSXRMplsTETunnelDown OID

where do I see this trap in GUI? In Problems view I do not receive it. I want to see it even if Zabbix is not able to translate it (if we say that there is a misconficuration with MIB files)


Thank you

[Hamardaban]

You can see the contents of the trap in the "lastdata" section. Provided that you set everything up correctly. And yet-zabix is not engaged in formatting or converting snmp traps and stores them as text or string, cutting off what did not fit. You can configure formatting and conversion in snmptt.

some links:
https://www.zabbix.com/documentation...itemtypes/snmp
https://www.zabbix.com/documentation...types/snmptrap.
https://blog.zabbix.com/snmp-traps-in-zabbix/8210/
https://blog.zabbix.com/zabbix-snmp-...gure-it/10345/

[manosnms]

I thought that I was able to see the traps in Problems section....where I have the severity......this is not possible?

So what do I see in Problems section? the polling from Zabbix to the elements?


Thank you!

[Hamardaban]

In the "problems" section, you can see the traps that triggered the trigger.

[manosnms]

the traps that triggered the trigger ??? could you please explain this? are the traps that generated from the network elements and received by zabbix?
thank you

[Hamardaban]

Read the information on the links I wrote earlier

[manosnms]

I did have a quick look. even one of them was my basic help to configure it. even though it does not answer to my question

In the problem section are the traps that generated from the network elements and received by zabbix?


thank you for your support!

[Hamardaban]

The chain is as follows: network device - > receiver and handler of traps -> zabix data element --if the trigger is configured and it triggered—> event generation —> display in problems.

https://www.zabbix.com/documentation/current/manual/config/triggers

https://www.zabbix.com/documentation/current/manual/config/events

[manosnms]

thank you. so my problem is somewhere in zabix data element --if the trigger is configured and it triggered—> event generation —> display in problems.

since i receive the traps and the script handles them

thank you once more

[tim.mooney]

If you're looking for this trap to be identified as a problem, and therefore appear in the Problems display, you maybe should focus on the "if the trigger is configured and it triggered" part.

Just because Zabbix received an SNMP trap, it doesn't just assume that means there's a problem. You have to configure triggers (thresholds) for Zabbix to identify that "this trap is a problem", what its severity is, etc.
