Hi folks,
I'm sharing a new template I've developed to monitor Splunk Enterprise using the Splunk REST API. This template provides comprehensive monitoring of license status, server health, system information, and configuration.
Licesing monitoring:
- Quota usage (peers, slaves, total, used %)
- Automatic license discovery with LLD, filtering the default Splunk licenses (macro not matches. ^F+D*$)
- Monitor each license individually
- License State
- Licenses type
- Trigger for license caducity (60d info, 30d warn, 15d avg, 5d high, <1d crit) all configurable by macros
- Trigger license expired (critical)
- Trigger for quota user % (>80, >90%, >95%, 100%)
Health moitoring:
- Overall health of splunkd
- File Monitor Health
- Http Event Collector Health (HEC)
- Index Processor Health
- Resource Usage Health
- Search Scheduler Health
- Workload Management Health
System information:
- Splunk version and build
- CPU Architecture
- Ports configuration
- Path configuration (Splunk_DB, Splunk_HOME)
Other features:
- I tried to avoid many api calls using 1 master call (for 3 endpoints) and then all other items are Dependant item with "Discarded with heartbeat" preprocessing.
- Preprocessing for remove sensitive data (pass4SymmKey) before zabbix "saves" on the raw item (javascript preprocessing to remove the key).
- Triggers with dependencies (avoiding duplicated alerts).
- Macro driven configuration
- Also has some triggers for check API connectivity ( No data for 30 minutes )
Required Macros:
- {$SPLUNK.ENTERPRISE.API.BASEURL} - API URL (e.g., https://mysplunk.com:8089)
- {$SPLUNK.ENTERPRISE.API.USER} - API Username
- {$SPLUNK.ENTERPRISE.API.PASSWORD} - API Password
API Endpoints Used:
- /services/licenser/licenses​ (for Discovery rule)
- /services/licenser/usage/license_usage
- /services/server/health/splunkd/details
- /services/server/info
- /services/server/settings
Tested on:
- Splunk Enterprise Developer License v9.4.1 version (onprem, proxmox vm)
- Following the REST API v10 guide https://help.splunk.com/en/splunk-en...reference-list
- Zabbix 7.4.6 (but I think that will work on any 7.x and 6.x versions)
Github: https://github.com/guillerg86/zabbix-splunk
I'd love to hear your feedback, suggestions, or improvements! If you have ideas for additional features, encounter any issues, or want to contribute to the template, please feel free.
